TYPE TESTS


We have Type Tested our Panel at CPRI for Short Circuit, Temperature Rise, and IP 54 & IP 55 Degree of Protection for enclosure. Find below the list of Type Tests undergone in CPRI.

• Type Test of complete verfication tests for 2500Amps on   LT Panel (M/s. ABB Switchgear Components)

• Complete Verification Tests in accordance with Standard / Specification as per IEC 61439-1:2011 & IEC 61439-2:2011 Sub-clause Nos. 10.10.2, 10.2.3.1, 10.9, 10.4, 10.11, 10.5, 10.2.6, 10.13, 10.2.7, 10.2.5, 10.2.3.3, 10.3, 10.2.2 & 10.12

• Type Test of complete verfication tests for 3200Amps on   LT Panel (M/s. ABB Switchgear Components)

• Complete Verification Tests in accordance with Standard / Specification as per IEC 61439-1:2011 & IEC 61439-2:2011 Sub-clause Nos. 10.10.2, 10.2.3.1, 10.9, 10.4, 10.11, 10.5, 10.2.6, 10.13, 10.2.7, 10.2.5, 10.2.3.3, 10.3, 10.2.2 & 10.12

• Type Test of complete verfication tests for 2500Amps on   LT Panel (M/s. Schneider Switchgear Components)

• Complete Verification Tests in accordance with Standard / Specification as per IEC 61439-1:2011 & IEC 61439-2:2011 Sub-clause Nos. 10.10.2, 10.2.3.1, 10.9, 10.4, 10.11, 10.5, 10.2.6, 10.13, 10.2.7, 10.2.5, 10.2.3.3, 10.3, 10.2.2 & 10.12

• Type Test of complete verfication tests for 3200Amps on   LT Panel (M/s. Schneider Switchgear Components)

• Complete Verification Tests in accordance with Standard / Specification as per IEC 61439-1:2011 & IEC 61439-2:2011 Sub-clause Nos. 10.10.2, 10.2.3.1, 10.9, 10.4, 10.11, 10.5, 10.2.6, 10.13, 10.2.7, 10.2.5, 10.2.3.3, 10.3, 10.2.2 & 10.12

• Temperature Rise Test for 5000Amps on bus bars for LT Panel

• Test in accordance with Standard / Specification stipulated in IS 8623 (Part 1) : 1993 / IEC Pub    60439 - 1 (1985) (RA-2008)

• Temperature Rise Test for 3200Amps on bus bars for LT Panel

• Test in accordance with Standard / Specification stipulated in IS 8623 (Part 1) : 1993 / IEC Pub    60439 - 1 (1985)

• Temperature Rise Test for 3200Amps on Bus bars for LT Bus    duct

• Test in accordance with Standard / Specification stipulated IS 8623 (Part 2) : 1993 / IEC    60439 - Part - 2 - 1987 (RU-2008)

• Verification of Short Circuit withstand strength: 65 kA rms for    1 Second & 143kA Peak on bus bars for LT Panel

• Test in accordance with Standard / Specification stipulated in sub-clause 8.2.3 of IS 8623
   (Part 1) : 1993 / IEC Pub 439 - 1 (1985)

• Verification of Short Circuit withstand strength: 65 kA rms for    1 Second & 143kA Peak on bus bars for LT Bus duct

• Test in accordance with Standard / Specification stipulated in sub-clause 8.2.3 of IS 8623
   (Part 2) : 1993 / IEC Pub 439 - 2 (1987)

• Verification of Short Circuit withstand strength: 50 kA rms for    1 Second & 105kA Peak on bus bars for LT Panel

• Test in accordance with Standard / Specification stipulated in sub-clause 8.2.3 of IS 8623
   (Part 1) : 1993 / IEC Pub 439 - 1 (1985)

• Degree of Ingress Protection IP 55 Test (Outdoor)  for LT Panel

• Test in accordance with Standard / Specification stipulated in IS/IEC61439-1 Edition 1.0,    2009-01 Standard Test of IS/IEC 60529 Edition 2.1, 2001-02 Standard Clause 13.4

• Degree of Ingress Protection IP 54 Test (Indoor)  for LT Panel

• Test in accordance with Standard / Specification stipulated in IS 13947 (Part 1) : 1993    (reaffirmed 2004)
